Reticle Management Systems

Reticle Stockers & Management Systems

Reticle & Photomask Storage

These space saving reticle stockers automatically present the appropriate shelf to the user. An indicator light then illuminates the box or slot. Included is a PC based reticle management system with optional SECs/GEM. Track you reticles. Query the database for reticle status, usage history, and operator transactions.

12.5'

9.5'

10.5'

Room sized
storage locker
(sized to fit)

Box Capacity 5000
5X5 & 6X6

1360 Boxes
5X5

Vertical Box Orientation

Horizontal Box Orientation

1280 Boxes
6X6

This is an affordable reticle management system that deploys a space saving design with a full featured reticle management system. Just a quick bar code and the shelf presents itself to the operator. An indicator light illuminating the box for easy retrieval. Scan the retrieved box's bar code for a mistake proof transaction. The database knows every reticle's whereabouts, history, and operator interaction. Multiple systems can be tied together. Control can be by your FAB's host or through the system's PC based reticle manager. These lockers are sized to fit your available space/s. Shelves are adjustable making it possible to accommodate multiple box sizes.

Made in USA

www.ReticleStorage.com
